QV-600 Vein Finder

Functions

QV-600 Vein Finder has various user-defined functions, which can adapt to different ages, body shapes, skin colors, weights and various operating environments. And it can be used for elbow puncture, plastic surgery and infant puncture.

Twelve Colors: Suitable for different skin colors or environments.
Three Sizes: Suitable for adults, children and newborns.
Six Levels of Brightness: Adjust the projection image to the most comfortable brightness.
Inversion Mode: Adapt to user preference.
Enhancement Mode: Increase the clarity of thin and deep blood vessel.
Software Hair Removal: Eliminate hair interference in vein image.
Puncture Guide Lines: Indicate the best puncture position.
Five Mixture Colors: Show the depth information of veins.
Sleep Mode: Enter into low power consumption mode when the user needs short intervals and can be waked up quickly. Sleep time can be set.
Photograph: Store venous images for medical staff to track and analyze pathology.
Image storage capacity：6000 sets, accessed by computer.
Electric Quantity Monitoring: Display on the LCD and alert when battery is low. Automatical shutdown without operation for 35 minutes.
Thirteen Languages

Technical Parameters
Infrared light detection without harm to human body.
Infrared Wave: 760-940nm
Infrared detection depth: 0-10mm
Best detection distance: 18-30cm
Accuracy of blood vessel position: ±0.3mm
Accuracy of blood vessel resolution: ≤0.3mm
Low working noise: ≤35dB
The battery capacity can be displayed.
Low Battery capacity prompt.
Samsung 4800mAh rechargeable lithium battery 3.5 hours continuous working time.
DLP projection technology.
Power supply of charging: Input 100V-240V 50Hz-60Hz AC, Output 5V 4.5A DC
Weight: 450g
Size: 24cm(L)*6cm(W)*6.5(H)cm
